SL-D301
Digital Slit Lamp
The SL-D301 is a classic and economical digital slit lamp with tower illumination especially designed with a stereoscopic converging bio-microscope, with excellent optics of the Galilean type that produces a sharp and clear view.
The halogen illumination and 9 mm field of view in combination with 3 magnification selections (10x, 16x & 25x) assist you in a wide range of screening applications. The SL-D301 is compatible with the optional Topcon DC-4 digital camera which offers you high resolution still imaging and video capabilities with auto exposure and smart capture function.
Key Features
- Three magnifications; 10x, 16x and 25x
- Blue filter, Red-free filter, ND filter, UV cut filter and IR cut filter
- Halogen illumination
- Galilean optics conversion
- Topcon DC-4 digital camera compatible
| MICROSCOPE: | |
| Type | Galilean type |
| Magnification Selection | 3 step by drum rotation |
| Eyepiece | 12.5x |
| Magnification Step | 10x / 16x / 25x |
| Magnification Ration (Field of View) | 10x (φ22.5mm) |
| 16x (φ14.1mm) | |
| 25x (φ8.8mm) | |
| Diopter Adjustment Range | -5D to +5D |
| SLIT ILLUMINATION: | |
| Slit Width | Continuos from 0 to 9mm (9mm circle) |
| Slit Length | Continuos from 1 to 8mm |
| Aperture Diameter | φ9, 8, 5, 3, 2, 1, 0.2mm |
| Slit Direction | Vertical to horizontal can be altered gradually |
| Inclination: 5 / 10 / 15 / 20 deg | |
| Filter | Blue filter, Red-free filter, ND filter (13% transmission), UV cut (normal use), IR cut (normal use) |
| Illumination Lamp | Halogen |
Not Available
Not Available
OPTIONAL ACCESSORIES
Topcon DC-4 Digital Camera
BG-2GN Background Illumination
Yellow Filter
